GGJIA Led High Bay LED Lights White Series 0-10V Dimmable, 5' Cable with US Plug
- $54.99
$59.99- $54.99
- Unit price
- per
5% OFF Automatically Applied On Carts Over $299 - 👉Learn More
💡Summer Flash Sale 10% OFF
Discount code: SUM10
Copied
Size:
Watt Guide
Subtotal:
$54.99
10 customers are viewing this product
Couldn't load pickup availability
Free Shipping
Free shipping from local warehouses in the US and Canada.
Free Returns
We have a 30-day return policy, which means you have 30 days after receiving your item to request a return.
5 Years Warranty
Warranty duration varies by product. See warranty details for specific terms.
Pack
May ship in different packs than selected. Total quantity guaranteed.
Applications
• Auto Dealerships
• Manufacturing
• Commercial
• Storage Facilities
• Gymnasiums
• Warehouses
• Industrial
• Max Delivered Lumens:
22500-36000lm
• Operating Temperature Range:
-31°F to 122°F (-35°C to 50°C)
• Input Power:
Selectable 100% - 80% - 60%
• Estimated L70 Lifetime @ 25˚C (77˚F):
>70000
• Input Voltage:
AC100-277V
• Power Factor:
>0.9 at full load
• Dimmable:
0-10V
• Total Harmonic Distortion:
<20% at full load
• 150 LPW
• Waterproof Rating:
IP65
• CRI:
≥ 70
• Limited Warranty:
5-Year
Document
User Guide
📝High Bay Light Installation Instructions 📝Practical Guide for Installing and Maintaining LED High Bay Lights 📝The Complete Buyer's Guide (100W to 400W) 📝What's Waterproof IP65? 📝What's 120° Beam Angle? 📝What's Led Shop Lights Dimmable? 📝Why Warehouse Lighting Design Matters?
❮
❯
Description
x
Key Features
One Fixture, Three Wattages
Adjust output on-site using the built-in wattage selector. Choose between 150W (22,500 lm), 120W (18,000 lm), and 90W (13,500 lm) without changing fixtures. This flexibility allows installers to match actual ceiling height and footcandle requirements without stocking multiple models.
Engineered for Project Flexibility
Designed for contractors, distributors and facility managers who need a single solution for multiple applications. The same fixture can illuminate ceilings as low as 14 ft using the 90W setting or ceilings up to 22–24 ft using the 150W setting. One SKU simplifies inventory management while covering a wide range of commercial projects.
0-10V Dimmable + Wattage Switch = Maximum Energy Control
Combine selectable wattage with integrated 0-10V dimming for precise lighting control. Set the fixture to 60%, 80% or 100%, then adjust output from 100% down to 1% through a compatible dimmer, occupancy sensor or building management system. This dual-control approach maximizes energy savings while maintaining required illumination levels.
White Architectural Housing
Finished with a durable white powder-coated aluminum housing, making it ideal for applications where traditional black industrial fixtures may appear visually intrusive. Popular in retail environments, fitness centers, finished workshops, schools and food-processing facilities. Features the same die-cast aluminum construction and IP65 protection as our Black Series high bays.
DLC Premium Qualified at Any Wattage
DLC Premium certification applies across all three wattage settings. Utility rebates can typically be claimed based on the wattage installed and documented during commissioning. While lower wattage settings may qualify for smaller rebate amounts, they also reduce long-term operating costs and improve return on investment.
Same 5-Year Warranty as Fixed-Wattage Models
The selectable wattage feature does not affect reliability or warranty coverage. All three operating modes are tested and rated for L70 50,000+ hours of service life. Any manufacturing defect under any wattage setting is covered by GGJIA's 5-year replacement warranty.
Best Applications
- Multi-Site Retrofit Projects — One fixture model accommodates varying ceiling heights and lighting requirements across multiple facilities.
- Distributor Inventory Simplification — A single SKU replaces multiple wattage-specific models, reducing inventory complexity.
- Spec-As-You-Go Installations — Final wattage can be selected during commissioning based on actual light measurements and customer preference.
- Warehouses with Mixed Ceiling Heights — Use lower wattage settings in bulk-storage areas and higher wattage settings in picking aisles while maintaining a consistent fixture appearance.
- Phased Facility Expansions — Begin operation at lower wattage levels and increase output as occupancy, inventory or production demands grow.
- Commercial Gyms & Recreation Centers — Fine-tune light levels based on activity zones without replacing fixtures.
- Retail & Showroom Spaces — Achieve target footcandle levels without over-lighting the space, reducing operating costs from day one.
Frequently asked questions
-
How do I change the wattage setting?
A wattage selector switch is located on the back of the driver compartment. Move the switch to one of 3 labeled positions (90W, 120W, 150W). The change takes effect immediately on power-on. Document the setting on the installation log for warranty and rebate tracking.
-
Does the wattage setting affect warranty?
No. All 3 wattage settings are factory-tested and warrantied identically. The 5-year warranty applies regardless of which mode the fixture is operated at.
-
Can I change the wattage during operation?
No. Wattage must be changed with the fixture de-energized (power off, allow 30 seconds for capacitors to discharge). Changing wattage while powered can damage the driver and voids the warranty.
-
How does utility rebate work with adjustable wattage?
Utilities calculate rebate based on the connected load (the wattage setting at installation), not the maximum capacity. If you install at 90W, you claim 90W rebate; at 150W, you claim 150W rebate. Most utility programs use the lower of the spec sheet maximum and actual installed wattage. Document your installed wattage with your rebate application.
-
What's the difference vs the HB Black Series?
The Black Series is a fixed 150W fixture in a black housing — slightly lower price, no wattage flexibility, classic commercial industrial look. The White Series is the adjustable-wattage version in a white housing — typically priced 5–10% higher but worth it for any project with uncertain wattage requirements or aesthetic preference for white.
-
Is the white finish the same powder-coat as competitor brands?
Yes. The white powder coat is RAL 9003 (signal white), the standard architectural white used across the industry. It's UV-resistant and color-stable for outdoor applications, though we recommend the Black Series for direct outdoor exposure.
-
Can I use this on a 277V three-phase commercial circuit?
Yes. The driver accepts 100-277V AC, covering all single-phase and three-phase commercial wiring including 277V phase-to-neutral, 240V split-phase and 208V three-phase. For 480V industrial circuits, use our high-voltage variant (contact sales@ggjia-led.com).
-
How does this work with a 0-10V dimmer?
Connect the violet (positive 0-10V) and gray (negative/0V) leads to your 0-10V dimmer or BMS. The fixture dims smoothly from 1% to 100% of the selected wattage setting. For example, at 150W setting with 50% dimming, actual power consumption is 75W.
-
Can I daisy-chain multiple fixtures on a single dimmer?
Yes. A standard 0-10V dimmer typically supports 10–20 fixtures on a single control loop. The GGJIA 0-10V Dimmer Switch supports up to 20 fixtures per zone. Beyond 20 fixtures, use multiple dimmer zones or a centralized BMS controller.
